AML
EQUIPMENTS
Robots
-
Indy7 & Bin picking Robot system
- Purpose
- bin picking testing robot
- Model
- Indy7
- Location
- Tip 301
-
UR10 collaboration robot
- Purpose
- Collaboration with other equipments
- Model
- UR10
- Location
- Tip 301
-
LCD panel Transport Robot
- Purpose
- Testing to transfer LCD panel
- Location
- Tip 301
-
TOSHIBA scara handling Robot
- Purpose
- Testing bin picking with scara robot
- Model
- THL500
- Location
- Tip 516
-
XYZ dispenser stage
- Purpose
- 3-way(x,y,z) control test
- Location
- Tip 301
-
A multi-joint robot
- Purpose
- Multi-joint robot control test
- Model
- ROBO 005
- Location
- Tip 516
-
Ultrasonic welder
- Purpose
- an ultrasonic fusion test
- Model
- FST-1530L
- Location
- FST-1530L
-
HYUNDAI Industrial Robot
- Purpose
- Robot machining
- Location
- Tip 301
-
HYUNDAI Industrial Robot
- Purpose
- Robot machining
- Model
- HH7
- Location
- Tip 301
Measuring equipment
-
Leica Absolute Tracker AT960
- Purpose
- 플래그쉽 6자유도 레이저트래커 (완전 6DoF 대응 트래커, 더 높은 측정범위와 정밀도, 실시간 데이터 전송 및 제어 시스템 연동)
- Model
- Leica AT960
- Location
- TIP 301
-
Leica Absolute Tracker ATS600
- Purpose
- 3D 레이저 트래커(직접 스캐닝, 반사체 측정 모드, 선택적 스캐닝)
- Model
- Leica ATS600
- Location
- TIP 301
-
Alicona Tool Shape Meter
- Purpose
- To measure matching tool shape and surface roughness
- Model
- Infinite Focus G6
- Location
- Tip 301
- spec
- Min.Vertical resolution : 10nm
- Measurement range
- 200*200*100 [mm^3]
,Tilt : -15~90 [degree]
